Duplex/By-pass Motor
1. Rear cover (* "p.169")
2. Right rear cover (* "p.170")
3. Open the controller box (* "p.287").
4. Duplex/by-pass motor bracket [A] ( x 2, x 1,  x 1)
5. Duplex/by-pass motor [A] ( x 4, belt x 1)
Toner Transport Motor
1. Rear cover (* "p.169")
2. Open the controller box (* "p.287")
4. Replacement and Adjustment
240
4
