Shift Tray (D388)
Paper Capacity:
250 sheet (A4/ 8
1/2
” x 11
1/2
” or smaller: 80g/m
2
/ 20 lbs)
125 sheet (B4 8
1/2
” x 11
1/2
” or larger: 80g/m
2
/ 20 lbs)
Paper Size:
Standard sizes
A6 SEF to A3, HLT to DLT
Non-standard sizes
Width: 90 to 305 mm
Length: 148 to 600 mm
Paper Weight: 52-256 g/m
2
/ 14 - 68 lbs
Power Consumption: Max 10W (Power is supplied from the mainframe.)
Dimension (W x D x H): 423 mm x 468 mm x 114 mm (16.7” x 18.4” x 4.5”)
Weight: Approx. 2kg (4.4lbs)
1-bin Tray Unit (D414)
Paper Size:
Standard Size:
A3 /DLT to A5/ HLT SEF
Paper Weight: 60 to 169 g/m
2
, 16 to 45 lb.
Tray Capacity: 125 sheets (80 g/m
2
, 20 lb., A4)
Power Source: DC 24 V, 5 V (from the copier)
Power Consumption: Less than 1 W
Weight: 1.7 kg
Size (W x D x H): 565 mm x 410 mm x 115 mm (22.2” x 16.1” x 4.5”)
1. Appendix: Specifications
32
