Paper Feed Unit Installation (D351)
Accessory Check
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Securing bracket 2
2 Screw (M4x10) 2
3 Spring Washer Screw 1
4 Knob screw 3
Installation Procedure
• Turn off the main switch of the copier and unplug the power cord before you start the installation
procedure.
• You need two or more persons to lift the copier. The copier is highly unstable when lifted by one
person, and may cause injury or property damage.
• Do not lift the copier with the paper feed unit installed. The handle and grips may be damaged.
2. Installation
46
