PSU
PSU bracket
1. Rear cover (*p.169 "Rear Cover")
2. Ventilation duct [A] ( x 2)
3. PSU bracket [B] ( x 6, x All, x All)
PSU board
1. Rear cover (*p.169 "Rear Cover")
2. Ventilation duct (see "PSU bracket")
3. PSU board [A] ( x 11, all s, all s)
4. Replacement and Adjustment
292
4
