Ricoh MPC 2800 AT-C2 User Manual

By-pass Paper Size Sensor and By-pass Paper Length Sensor
1. Open the by-pass tray [A].
2. Move the side fences to the center.
3. By-pass tray cover [B] ( x 4)
4. By-pass paper size sensor [A] ( x 1).
5. By-pass paper length sensor [B] ( x 1)
4. Replacement and Adjustment
268
4
