Scanner Unit
Exposure Glass
1. Glass cover [A] ( x 4)
2. ARDF exposure glass [B]
3. Rear scale [C] ( x 3)
4. Exposure glass with left scale [D]
Position the white marker [E] at the rear-left corner and the black or blue marker at the front-left
corner when you reattach the ARDF exposure glass.
Scanner Unit
175
4
