Adjustment Procedure
1. Enter SP2-109-003.
2. Print out the test pattern (14: 1-dot trimming pattern) with SP2-109-003.
• Registration can change slightly as shown on the previous page. Print some pages of the 1-dot
trimming pattern for step 3 and 4. Then average the leading edge and side-to-side registration
values, and adjust each SP mode.
3. Do the leading edge registration adjustment.
1) Check the leading edge registration and adjust it with SP1-001.
2) Select the adjustment conditions (paper type and process line speed).
3) Input the value. Then press the  key.
4) Generate a trim pattern to check the leading edge adjustment.
4. Do the side-to-side registration adjustment.
1) Check the side-to-side registration and adjust it with SP1-002.
2) Select the adjustment conditions (paper feed station).
3) Input the value. Then press the  key.
4) Generate a trim pattern to check the leading edge adjustment.
Erase Margin Adjustment
• Adjust the erase margin C and D only if the registration (main scan and sub scan) cannot be adjusted
within the standard values. Do the registration adjustment after adjusting the erase margin C and D,
and then adjust the erase margin A and B.
Image Adjustment
161
4
