Ricoh MPC 2800 AT-C2 User Manual

Duplex Unit
Duplex Unit
1. Rear cover (*p.169)
2. Right rear cover (*p.170)
3. Open the lower door [A] of the duplex unit.
4. Release the tab [B] and remove the lower door (spring x 2).
5. Open the right door.
6. Release the front link [A] ( x 1).
7. Keep the right door fully open.
Duplex Unit
279
4
