1-Bin Tray Unit (D414)
Component Check
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 1-Bin Tray Unit 1
2 End-fence 1
3 Tray Support Bar 1
4 Screws (M3 x 16) 2
5 Tray 1
Installation Procedure
• Unplug the copier power cord before starting the following procedure.
If the bridge unit (D386) has already been installed in the machine, remove it before installing 1-bin tray
unit (D414). This will make it easier for you to do the following procedure.
1. Remove all tapes.
2. Open the right door of the machine.
2. Installation
