• The picture below shows how to use the screwdriver to remove the screws of the paper transfer
contact motor.
Duplex Inverter Motor
1. Open the right door.
2. Right door cover, right door rear cover (* "p.269")
3. Duplex door [A] (2 hooks)
4. Duplex guide plate [B] ( x 3, 2 hooks)
4. Replacement and Adjustment
238
4

Ricoh MPC 2800 AT-C2 Specifications

General

Brand	Ricoh
Model	MPC 2800 AT-C2
Category	All in One Printer
Language	English
