2. Toner collection unit [A] ( x 6, x 1)
Paper Feed Clutches
1. Rear cover (* "p.169")
2. PSU bracket (* "p.292")
3. Release five clamps, and then turn the harness [A] aside.
4. Replacement and Adjustment
242
4
