Optional Equipment
ARDF (D366)
Paper Size/Weight:
Simplex
Size A3 to A5, DLT to HLT
Weight 40 to 128 g/m
2
(10 to 34 lb.)
Duplex
Size A3 to A5, DLT to HLT
Weight 52 to 105 g/m
2
(14 to 28 lb.)
Table Capacity: 50 sheets (80 g/m
2
, 20 lb)
Original Standard Position: Rear left corner
Separation: Feed belt and separation roller
Original Transport: Roller transport
Original Feed Order: From the top original
Supported Magnification Ratios:
Copy - 32 to 200 %
Fax
Color 32.6 to 200 %
Black & white 48.9 to 200 %
Power Source: DC 24V, 5V from the scanner unit
Power Consumption: 50 W or less
Dimensions (W × D × H) : 550 mm x 491 mm x 120 mm (21.7" x 19.3" x 4.7")
Weight: 10 kg (22 lb.)
Paper Feed Unit (D387)
Paper Feed System: FRR
Paper Height Detection: 5 steps (100%, 70%, 30%, 10% (Near end), and Empty)
Capacity: 550 sheets
Paper Weight: 80 g/m
2
(21 lb.)
1. Appendix: Specifications
24
