5. Pressure roller bearings [A] (front and rear)
Fusing/Paper Exit Fan
1. Open the right door.
2. Rear cover (*p.169 "Rear Cover")
3. Right rear cover (*p.170 "Right Rear Cover")
4. High voltage supply board bracket (*p.294 "High Voltage Supply Board Bracket")
5. Fusing/paper exit fan [A] ( x 1,  x 1, hook x 2)
When Reinstalling the Fan
Make sure that the fusing/paper exit fan is installed with its decal facing to the right side.
Fusing
261
4
