2. Remove the slot cover [A] ( x 1).
3. Attach the Gigabit Ethernet controller [A] into the slot [B] ( x 2).
Check All Connections
1. Plug in the power cord. Then turn on the main switch.
2. Enter the printer user mode. Then print the configuration page.
User Tools > Printer Settings > List Test Print > Config. Page
All installed options are shown in the “System Reference” column.
Controller Options
149
2
