Ricoh MPC 2800 AT-C2 User Manual

Heating Roller Thermistor
1. Fusing upper cover (*p.249 "Pressure Roller Lamp")
2. Top frame (*p.253 "Fusing Belt and Pressure Roller")
3. Release the connector [A].
4. Heating roller thermistor [A] ( x 1)
Pressure Roller Thermistor and Thermostat
1. Fusing upper cover (*p.249 "Pressure Roller Lamp")
2. Pressure roller (*p.253 "Fusing Belt and Pressure Roller")
4. Replacement and Adjustment
258
4
