• WEP Key
SP Mode and UP Mode Settings for IEEE 802.11 a/g, g Wireless LAN
The following SP commands and UP modes can be set for IEEE 802.11 a/g, g.
SP No. Name Function
5840-006 Channel MAX Sets the maximum range of the channel settings for the country.
5840-007 Channel MIN
Sets the minimum range of the channels settings allowed for your
country.
5840-011 WEP Key Select Used to select the WEP key (Default: 00).
UP mode Name Function
SSID Used to confirm the current SSID setting.
WEP Key Used to confirm the current WEP key setting.
WEP Mode
Used to show the maximum length of the string that can be used
for the WEP Key entry.
Bluetooth
• Unplug the main machine power cord before you do the following procedure.
You can only install one of the following network interfaces at a time: (IEEE 802.11 a/g, g (Wireless LAN),
IEEE1284, Bluetooth).
2. Installation
134
