Bridge Unit (D386)
Component Check
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 Bridge Unit 1
2 Frame Cover 1
3 Knob screw 1
4 Long knob screw 1
5 Holder bracket 1
6 Guide 2
Installation Procedure
• Unplug the copier power cord before starting the following procedure.
2. Installation
74
