Ricoh MPC 2800 AT-C2 User Manual

1. Turn off the main power switch.
2. Open the front door and remove the screw [A].
3. Close the front door.
4. Pull out tray 1 [B].
5. Open the toner collection bottle door [C].
6. Pull out the toner collection bottle [D].
Second Duct Fan
1. Rear cover (*p.169 "Rear Cover")
2. Right rear cover (*p.170 "Right Rear Cover")
3. Open the controller box (*p.287 "Controller Box")
4. Replacement and Adjustment
204
4
