6. Drum/Development drive motor
(K, Y, M, C)
Drives the color drum unit and development unit (K, Y, M, C).
7. Paper feed clutch Switches the drive power between tray 1 and tray 2.
8. Paper feed motor: Drives the paper feed mechanisms (tray 1/tray 2).
9. By-pass feed clutch:
Turns on/off the drive power to the by-pass pick-up, feed and
separation rollers.
10. Registration motor: Drives the registration roller.
11. By-pass/duplex feed motor:
Drives the by-pass pick-up, feed and separation roller, and
duplex transport rollers.
12. Paper transfer contact motor:
Moves the paper transfer roller in contact with the image transfer
belt.
13. ITB drive motor: Drives the image transfer belt unit.
14. Duplex inverter motor Drives the duplex inverter rollers and duplex transport rollers.
15. Fusing/paper exit motor: Drives the fusing unit and paper exit section.
1. Product Information
18
