Registration No.
User Code
E-mail
Protection Code
Fax Destination
Fax Option
Group Name
Key Display
Select Title
Folder
Local Authentication
Folder Authentication
Account ACL
New Document Initial ACL
LDAP Authentication
Download
1. Prepare a formatted SD card.
2. Make sure that the write-protection on the SD card is off.
3. Turn off the main power switch of the main machine.
4. Remove the SD slot cover at the left rear side of the machine ( x 1).
5. Install the SD card into SD card slot 2 (for service use).
6. Turn on the main power switch.
7. Enter the SP mode.
8. Do SP5-846-051 (Backup All Addr Book).
9. Exit the SP mode, and then turn off the main power switch.
10. Remove the SD card form SD card slot 2.
11. Install the SD slot cover.
If the capacity of SD card is not enough to store the local user information, an error message is
displayed.
Carefully handle the SD card, which contains user information. Do not take it back to your
location.
Upload
1. Turn off the main power switch of the main machine.
2. Remove the SD slot cover at the left rear side of the machine ( x 1).
3. Install the SD card, which has already been uploaded, into SD card slot 2.
4. Turn on the main power switch.
5. System Maintenance Reference
314
5
