Page #839 background image
6008 8 Inverter Motor Reverse -
6008 9 Feed Clutch -
6008 10 Feed Solenoid Pick-up Solenoid
6008 11 Inverter Solenoid -
6008 12 Stamp Stamp Solenoid
1000-Sheet Booklet Finisher (D372)
6143 Display Description
6143 1 Shift Motor Shift Tray Motor
6143 2 Entrance Motor -
6143 3 Staple Relay Motor Stapler Unit Motor
6143 4 Knock Solenoid
6143 5 Junction Gate SOL 1 Proof Tray Gate Solenoid
6143 6 Junction Gate SOL 2 Staple Tray Gate Solenoid
6143 7 Folder Roller Rotation Motor Fold Roller Motor
6143 8 Staple Motor Staple Fold Motor
6143 10 Exit Guide Plate Motor -
6143 11 Shift Relay Motor Upper Transport Motor
6143 12 Tray Motor Shift Tray Motor
6143 13 Stack Feed-out Motor Positioning Roller Solenoid
6143 14 Stuck Relay1 Motor Upper Clamp Roller Motor
6143 15 Stuck Relay1 Release Motor Upper Retraction Motor
6143 16 Rear Edge Fence Drive Motor Bottom Fence Lift Motor
6143 17 Folder Plate Motor -
6143 18 Drive Roller Oscillating Motor Lower Retraction Motor
System Service Mode
483
8
