Programming Tables
A-53
Command Quick Reference
Page Command Name Form and Data Digit Default User
21-24 Macro: Select Frequency of CTCSS (RBPW) 27 (tone code) *
See Page 10-5 for frequencies of 67.0
through 203.5. Above 203.5, use:
33 = 210.7
24 = 218.1
35 = 225.7
36 = 233.6
37 = 241.8
38 = 250.3
none
21-25 Enable/Disable CTCSS Encoder (RBPW) 48 x *
1 = Enable
0 = Disable
disabled
21-25 Macro: Enable/Disable CTCSS Encoder (RBPW) 28 x *
1 = Enable
0 = Disable
disabled
21-26 Enable/Disable CTCSS Decoder (RBPW) 49 x *
1 = Enable
0 = Disable
disabled
21-26 Macro: Enable/Disable CTCSS Decoder (RBPW) 29 x *
1 = Enable
0 = Disable
disabled
21-27 Send Current Settings (RBPW) 39 * none
21-28
Remote Base User Function Outputs
21-29 Select RBI-1 Number of User Function
Outputs in Group
(PW) 39 90 (number in group) * 8
21-30 Select Individual RBI-1 User Function
Outputs Latched ON
(RBPW) 11 (list of outputs 1-8) * none
21-30 Select Individual RBI-1 User Function
Outputs Latched OFF
(RBPW) 12 (list of outputs 1-8) * none
21-31 Enter RBI-1 User Function Output Group (RBPW) 10 (decimal number) *
The decimal number can be set to 0
through the maximum set in the Select
Number of User Function Outputs
command. The following ranges are
available by number of outputs:
0 = none available
1 = 0 or 1
2 = 0 thru 3
3 = 0 thru 7
4 = 0 thru 15
5 = 0 thru 31
6 = 0 thru 63
7 = 0 thru 127
8 = 0 thru 255
none
