SET.12 of 32 Settings Sheets for the SEL-311C Relay
Relay Settings (Serial Port Command SET and Front Panel)
SEL-311C Relay Instruction Manual Date Code 20060320
Date________________
Level 1 time delay (2.00–16000.00 cycles in 0.25-cycle steps) 81D1D =
Level 2 pickup (OFF, 41.00–65.00 Hz)
81D2P =
Level 2 time delay (2.00–16000.00 cycles in 0.25-cycle steps)
81D2D =
Level 3 pickup (OFF, 41.00–65.00 Hz)
81D3P =
Level 3 time delay (2.00–16000.00 cycles in 0.25-cycle steps)
81D3D =
Level 4 pickup (OFF, 41.00–65.00 Hz)
81D4P =
Level 4 time delay (2.00–16000.00 cycles in 0.25-cycle steps)
81D4D =
Level 5 pickup (OFF, 41.00–65.00 Hz)
81D5P =
Level 5 time delay (2.00–16000.00 cycles in 0.25-cycle steps)
81D5D =
Level 6 pickup (OFF, 41.00–65.00 Hz)
81D6P =
Level 6 time delay (2.00–16000.00 cycles in 0.25-cycle steps)
81D6D =
Reclosing Relay (See Table 6.2 and Table 6.3)
(Make the following settings if preceding enable setting E79 = 1–4.)
Open interval 1 time
(0.00–999999.00 cycles in 0.25-cycle steps)
79OI1 =
Open interval 2 time
(0.00–999999.00 cycles in 0.25-cycle steps)
79OI2 =
Open interval 3 time
(0.00–999999.00 cycles in 0.25-cycle steps)
79OI3 =
Open interval 4 time
(0.00–999999.00 cycles in 0.25-cycle steps)
79OI4 =
Reset time from reclose cycle
(0.00–999999.00 cycles in 0.25-cycle steps)
79RSD =
Reset time from lockout
(0.00–999999.00 cycles in 0.25-cycle steps)
79RSLD =
Reclose supervision time limit (OFF, 0.00–999999.00 cycles in
0.25-cycle steps) (set 79CLSD = 0.00 for most applications;
see Figure 6.2)
79CLSD =
Switch-Onto-Fault (See Figure 5.3)
(Make the following settings if preceding enable setting ESOTF = Y.)
Close enable time delay
(OFF, 0.00–16000.00 cycles in 0.25-cycle steps)
CLOEND =
52A enable time delay
(OFF, 0.00–16000.00 cycles in 0.25-cycle steps)
52AEND =
SOTF duration (0.50–16000.00 cycles in 0.25-cycle steps)
SOTFD =
