Schweitzer Engineering Laboratories SEL-311C - Page 356

SET.26 of 32 Settings Sheets for the SEL-311C Relay
Text Label Settings (Serial Port Command SET T)
SEL-311C Relay Instruction Manual Date Code 20060320
Date________________
Text Label Settings (Serial Port Command SET T)
Enter the following characters: 0–9, A–Z, #, &, @, -, /, ., space for each text label setting, subject to the specified
character limit. Enter NA to null a label.
Local Bit Labels (See Table 7.1 and Table 7.2)
Local Bit LB1 Name (14 characters) NLB1 =
Clear Local Bit LB1 Label (7 characters)
CLB1 =
Set Local Bit LB1 Label (7 characters)
SLB1 =
Pulse Local Bit LB1 Label (7 characters)
PLB1 =
Local Bit LB2 Name (14 characters)
NLB2 =
Clear Local Bit LB2 Label (7 characters)
CLB2 =
Set Local Bit LB2 Label (7 characters)
SLB2 =
Pulse Local Bit LB2 Label (7 characters)
PLB2 =
Local Bit LB3 Name (14 characters)
NLB3 =
Clear Local Bit LB3 Label (7 characters)
CLB3 =
Set Local Bit LB3 Label (7 characters)
SLB3 =
Pulse Local Bit LB3 Label (7 characters)
PLB3 =
Local Bit LB4 Name (14 characters)
NLB4 =
Clear Local Bit LB4 Label (7 characters)
CLB4 =
Set Local Bit LB4 Label (7 characters)
SLB4 =
Pulse Local Bit LB4 Label (7 characters)
PLB4 =
Local Bit LB5 Name (14 characters)
NLB5 =
Clear Local Bit LB5 Label (7 characters)
CLB5 =
Set Local Bit LB5 Label (7 characters)
SLB5 =
Pulse Local Bit LB5 Label (7 characters)
PLB5 =
Local Bit LB6 Name (14 characters)
NLB6 =
Clear Local Bit LB6 Label (7 characters)
CLB6 =
Set Local Bit LB6 Label (7 characters)
SLB6 =
Pulse Local Bit LB6 Label (7 characters)
PLB6 =
Local Bit LB7 Name (14 characters)
NLB7 =
Clear Local Bit LB7 Label (7 characters)
CLB7 =
Set Local Bit LB7 Label (7 characters)
SLB7 =
Pulse Local Bit LB7 Label (7 characters)
PLB7 =
