Schweitzer Engineering Laboratories SEL-311C - Page 357

Date _______________
Date Code 20060320 Instruction Manual SEL-311C Relay
SET.27 of 32Settings Sheets for the SEL-311C Relay
Text Label Settings (Serial Port Command SET T)
Local Bit LB8 Name (14 characters) NLB8 =
Clear Local Bit LB8 Label (7 characters)
CLB8 =
Set Local Bit LB8 Label (7 characters)
SLB8 =
Pulse Local Bit LB8 Label (7 characters)
PLB8 =
Local Bit LB9 Name (14 characters)
NLB9 =
Clear Local Bit LB9 Label (7 characters)
CLB9 =
Set Local Bit LB9 Label (7 characters)
SLB9 =
Pulse Local Bit LB9 Label (7 characters)
PLB9 =
Local Bit LB10 Name (14 characters)
NLB10 =
Clear Local Bit LB10 Label (7 characters)
CLB10 =
Set Local Bit LB10 Label (7 characters)
SLB10 =
Pulse Local Bit LB10 Label (7 characters)
PLB10 =
Local Bit LB11 Name (14 characters)
NLB11 =
Clear Local Bit LB11 Label (7 characters)
CLB11 =
Set Local Bit LB11 Label (7 characters)
SLB11 =
Pulse Local Bit LB11 Label (7 characters)
PLB11 =
Local Bit LB12 Name (14 characters)
NLB12 =
Clear Local Bit LB12 Label (7 characters)
CLB12 =
Set Local Bit LB12 Label (7 characters)
SLB12 =
Pulse Local Bit LB12 Label (7 characters)
PLB12 =
Local Bit LB13 Name (14 characters)
NLB13 =
Clear Local Bit LB13 Label (7 characters)
CLB13 =
Set Local Bit LB13 Label (7 characters)
SLB13 =
Pulse Local Bit LB13 Label (7 characters)
PLB13 =
Local Bit LB14 Name (14 characters)
NLB14 =
Clear Local Bit LB14 Label (7 characters)
CLB14 =
Set Local Bit LB14 Label (7 characters)
SLB14 =
Pulse Local Bit LB14 Label (7 characters)
PLB14 =
Local Bit LB15 Name (14 characters)
NLB15 =
Clear Local Bit LB15 Label (7 characters)
CLB15 =
Set Local Bit LB15 Label (7 characters)
SLB15 =
Pulse Local Bit LB15 Label (7 characters)
PLB15 =
