Schweitzer Engineering Laboratories SEL-311C - Page 358

SET.28 of 32 Settings Sheets for the SEL-311C Relay
Text Label Settings (Serial Port Command SET T)
SEL-311C Relay Instruction Manual Date Code 20060320
Date________________
Local Bit LB16 Name (14 characters) NLB16 =
Clear Local Bit LB16 Label (7 characters)
CLB16 =
Set Local Bit LB16 Label (7 characters)
SLB16 =
Pulse Local Bit LB16 Label (7 characters)
PLB16 =
Display Point Labels
(See Rotating Default Display (Only on Models With LCD) on page 7.36 and
Rotating Default Display on page 11.12)
Display if DP1 = logical 1 (16 characters) DP1_1 =
Display if DP1 = logical 0 (16 characters)
DP1_0 =
Display if DP2 = logical 1 (16 characters)
DP2_1 =
Display if DP2 = logical 0 (16 characters)
DP2_0 =
Display if DP3 = logical 1 (16 characters)
DP3_1 =
Display if DP3 = logical 0 (16 characters)
DP3_0 =
Display if DP4 = logical 1 (16 characters)
DP4_1 =
Display if DP4 = logical 0 (16 characters)
DP4_0 =
Display if DP5 = logical 1 (16 characters)
DP5_1 =
Display if DP5 = logical 0 (16 characters)
DP5_0 =
Display if DP6 = logical 1 (16 characters)
DP6_1 =
Display if DP6 = logical 0 (16 characters)
DP6_0 =
Display if DP7 = logical 1 (16 characters)
DP7_1 =
Display if DP7 = logical 0 (16 characters)
DP7_0 =
Display if DP8 = logical 1 (16 characters)
DP8_1 =
Display if DP8 = logical 0 (16 characters)
DP8_0 =
Display if DP9 = logical 1 (16 characters)
DP9_1 =
Display if DP9 = logical 0 (16 characters)
DP9_0 =
Display if DP10 = logical 1 (16 characters)
DP10_1 =
Display if DP10 = logical 0 (16 characters)
DP10_0 =
Display if DP11 = logical 1 (16 characters)
DP11_1 =
Display if DP11 = logical 0 (16 characters)
DP11_0 =
Display if DP12 = logical 1 (16 characters)
DP12_1 =
Display if DP12 = logical 0 (16 characters)
DP12_0 =
Display if DP13 = logical 1 (16 characters)
DP13_1 =
