12.17
Date Code 20060320 Instruction Manual SEL-311C Relay
Standard Event Reports and SER
Standard 15/30/60/180-Cycle Event Reports
b Both TMB5B and TMB6B asserted.
TMB B 7 8 TMB7B, TMB8B 7 M
IRRORED BITS channel B transmit bit 7 TMB7B asserted.
8M
IRRORED BITS channel B transmit bit 8 TMB8B asserted.
b Both TMB7B and TMB8B asserted.
RMB B 1 2 RMB1B, RMB2B 1 M
IRRORED BITS channel B receive bit 1 RMB1B asserted.
2M
IRRORED BITS channel B receive bit 2 RMB2B asserted.
b Both RMB1B and RMB2B asserted.
RMB B 3 4 RMB3B, RMB4B 3 M
IRRORED BITS channel B receive bit 3 RMB3B asserted.
4M
IRRORED BITS channel B receive bit 4 RMB4B asserted.
b Both RMB3B and RMB4B asserted.
RMB B 5 6 RMB5B, RMB6B 5 M
IRRORED BITS channel B receive bit 5 RMB5B asserted.
6M
IRRORED BITS channel B receive bit 6 RMB6B asserted.
b Both RMB5B and RMB6B asserted.
RMB B 7 8 RMB7B, RMB8B 7 MIRRORED BITS channel B receive bit 7 RMB7B asserted.
8M
IRRORED BITS channel B receive bit 8 RMB8B asserted.
b Both RMB7B and RMB8B asserted.
ROK ROKA, ROKB A M
IRRORED BITS channel A receive OK ROKA asserted.
BM
IRRORED BITS channel B receive OK ROKB asserted.
b Both ROKA and ROKB asserted.
RBAD RBADA, RBADB A MIRRORED BITS channel A extended outage RBADA asserted.
BM
IRRORED BITS channel B extended outage RBADB asserted.
b Both RBADA and RBADB asserted.
CBAD CBADA, CBADB A M
IRRORED BITS channel A unavailability CBADA asserted.
BM
IRRORED BITS channel B unavailability CBADB asserted.
b Both CBADA and CBADB asserted.
LBOK LBOKA, LBOKB A M
IRRORED BITS channel A loop back OK LBOKA asserted.
BM
IRRORED BITS channel A loop back OK LBOKB asserted.
b Both LBOKA and LBOKB asserted.
OC OC, CC o
c
OPE (Open) command executed.
CLO (Close) command executed.
Lcl RW 5 LB1–LB8 00–FF
Hex
a
Hex value of Relay Word 5, LB1–LB8, Local Bits
Lcl RW 6 LB9–LB16 00–FF
Hex
a
Hex value of Relay Word 6, LB9–LB16, Local Bits
Rem RW 7 RB1–RB8 00–FF
Hex
a
Hex value of Relay Word 7, RB1–RB8, Remote Bits
Rem RW 8 RB9–RB16 00–FF
Hex
a
Hex value of Relay Word 8, RB9–RB16, Remote Bits
Ltch RW 9 LT1–LT8 00–FF
Hex
a
Hex value of Relay Word 9, LT1–LT8, Latch Bits
Table 12.5 Communication Elements Event Report Columns (Sheet 3 of 4)
Column
Heading
Corresponding
Elements
(Relay Word Bits)
Symbol Definition
