SeaDoo GTX Series 2022 User Manual

Section 06 STEERING AND PROPULSION
Subsection 01 (STEERING)
219100893-028-016_a
1.2 Remove the steering column upper steer-
ing arm by removing the screws.
21910
0893-028-305_a
1. C-clamp retaining screws
1.3 Pull on steering column upward enough to
remove the lower steering arm.
219100893-028-306_a
1. Lift steering column
2. Slide lower
1.4 Slide out the cable from the steering arm.
Access can be improved by lifting the
steering l ever.
219100893-028-309_a
2. At rear of
the watercraft, disconnect ball joint
from jet p
ump nozzle a rm.
219100893-028-018_a
1. Steering cable bolt
2. Nozzle arm
3. Remove ball joint and jam nut from cable.
158 219100963-017

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
