SeaDoo GTX Series 2022 User Manual

INTRODUCTION
5. Apply several drops on bolt threads.
6. Tighten as required.
Threadlocker Application for Stud
Installation in Blind Holes
2
1
3
lmr2007-04
0-005_a
1. On stud th reads
2. On threads and in the hole
3. On retaini
ng nut threads
1. Clean threads (stud and hole) with solvent.
2. Apply
LOC
TITE 7649 (PRIMER)
on threads and
allow to d
ry.
3. Put 2 or 3 drops of proper strength Loctite
threadlocker on female threads and in hole.
NOTE: To avoid a hydro lock situation, do not ap-
ply too much Loctite.
4. Apply se
veral drops of proper strength Loctite
on stud t
hreads.
5. Install stud.
6. Install cover, part, etc.
7. Apply a
few drops of proper strength Loctite on
uncove
red stud threads.
8. Install and tighten retaining nut(s) as required.
Threadlocker Application for
Pre-Assembled Parts
A00A3OA
1
2
1. Apply her
e
2. Do not apply
1. Clean bolts and nuts with solvent.
2. Assemble components.
3. Tighten
nuts.
4. Apply a few drops of proper strength Loctite on
bolt/nut contact surfaces.
5. Avoid touching metal with tip of flask.
NOTE: Fo
r preventive maintenance on exist-
ing equ
ipment, retighten nuts and apply proper
streng
th Loctite on bolt/nut contact surfaces.
Threadlocker Application for an
Adjust
ment Screw
A00A3PA
1
2
1. Apply here
2. Plunger
1. Adjust screw to proper setting.
2. Apply a few drops of proper strength Loctite
threadlocker on screw/body contact surfaces.
3. Avoid touching metal with tip of flask.
XVI 219100963-002
