Section 06 ST EE RING AND PROPULSION
Subsection 03 (JET PUMP)
smr2009-006-016_a
1. Seallipfacingup
10. Install circlip.
smr2006-027-007_c
TYPICAL
1. Circli
p
11. Turn pump upside down.
12. Before
installing any other parts, pressurize jet
pump to
insure proper seal installation. Refer
to
LEA
K TEST
in this subsection.
13. Install impeller. Refer to
IMPELLER in this
subsection.
14. Mount in a vise the impeller remover/installer.
REQUIRED TOOL
IMPELLER
REMOVER/INSTALLER
(P/N 529 035 956)
1
F18J0PB
1. Impeller remover/installer tool
15. Install jet pump housing over tool.
F18J0QA
TYPICAL
16. Using a 30 mm socket, screw the impeller
shaft nut on clockwise.
17. Tighten nut as specified in exploded view.
smr2009-006-009_b
18. Apply 30 g (1.1 oz) of grease around nut.
219100963-019 199
