Guided Maintenance
12.4.5 Recording the Status of the HiPath 3000 V.24 Interfaces
You can use HiPath 3000/5000 Manager E to view the current status of the V.24 interfaces, in
which case the following information is provided.
● Status of the trunks (1 = active trunk, 0 = inactive trunk)
The individual trunks are assigned as follows:
DTR = HiPath 3000
DSR = Telephone
RTS = HiPath 3000
CTS = Telephone
This means, for example, that incorrectly connected or damaged cables can be deter-
mined (for more information on this, refer to the HiPath 3000/5000 Manager E Help).
● V.24 Monitoring
The number of sent/received bytes within a selected time period can be recorded and then
displayed/saved using a text editor (default = MS WordPad
®
).
The failure and restart of a V.24 interface generates an entry in the event log and releases a
remote error signal (V.24 failure = “Check printer” error message, V.24 restart = Withdrawal of
error message).
Activated features Status of activated features (on or off):
● Do Not Disturb
● Call forwarding (device status)
● Answer text
● Room monitor
● Telephone lock
● Suppress calling ID
● Call connection
● Disable incoming ringing
● Out of Hunt group/Group ringing
● Call waiting tone
● Direct Answering
● Call waiting terminating
● Ring transfer (only for MULAP)
● Call forwarding MULAP (only for MULAP)
Stations included List of the stations included
