Siemens HiPath 3000 Series - Interface-To-Interface Ranges

sysdat.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
2-81
Nur für den internen Gebrauch System Data
Interface-to-Interface Ranges
2.7 Interface-to-Interface Ranges
Telephone interface-to-interface ranges
Trunk connection and CorNet N/CorNet NQ ranges
The table below provides the maximum cable lengths for direct trunk connection and direct Cor-
Net N/CorNet NQ Direct Wiring. The values apply to ideal conditions, which means there can
be no joints, etc. The real conditions must be measured on-site.
Table 2-60 Telephone Interface-to-Interface Ranges (with J-Y (ST) 2x2x0.6, 0.6 mm di-
ameter)
Telephone Interfaces Range in m Loop resistance
in ohms
ISDN-S
0
point-to-point < 600 156
ISDN S
0
extended bus connection < 400 104
ISDN S
0
bus connection
1
1 Board-specific
< 60
for the HiPath 3800 board STMD3
(Q2217)
< 120
for all other S
0
boards
21
ISDN-S
0
wall outlet to terminal < 10 –
Analog users < 2000 520
U
P0/E
exchange to host (master) < 1000 230
U
P0/E
host to client (master/slave) < 100 23
Table 2-61 Cable Lengths for Trunk Connection and Direct CorNet N/CorNet NQ Direct
Wiring
Inter-
face
Cable Diameter Attenuation
per km
Max. Cable
Length
S
0
ICCS cable
J-2Y(ST)Y4x2x0.51 LG ICCS
Data5
0.51 mm 7,5 dB
at 96 kHz
800 m
Installation cable
J-2Y(ST)Y 10x2x0.6 ST III BD
0.6 mm 6.0 dB
at 96 kHz
1000 m
S
2M
A-2Y0F(L)2Y 10x2x0.6 (full PE
insulation, filled)
0.6 mm 17 dB
at 1 MHz
350 m
