Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
3.3.46 TS2N (old: TS2) [Not for U.S.], TS2R (not for U.S.)
Introduction
The board contains a four-wire interface with S
2M
code for connection to the public telecommu-
nications network or private networks.
Up to thirty trunk calls can be conducted simultaneously via the S
2M
interface. The total trans-
mission speed including signaling and synchronization is 2048 Mbps.
Two trace files are available:
● Implemented up to and including V4.0:
–TS2 (Trunk Module S2M) S30810-Q2913-X100 (Figure 3-118) - for use in HiPath 3550
(wall housing)
– TS2R (Trunk Module S2M Rack) S30810-K2913-Z100 (Figure 3-119) - for use in Hi-
Path 3500 (19-inch housing)
● Implemented in V5.0 and later:
– TS2N (old: TS2) [Trunk Module S2M] S30810-Q2913-X300 (Figure 3-118) - for use in
HiPath 3550 (wall housing)
– TS2R (Trunk Module S2M Rack) S30810-K2913-Z300 (Figure 3-119) - for use in Hi-
Path 3500 (19-inch housing)
Board usage is subject to the following restrictions:
● Only one TS2N/TS2R board allowed (primary multiplex access)
● For slot 7 or 9 only
To support country-specific CAS protocols, you can use the Euro-ISDN CAS gateway ECG.
The ECG cabinet is a protocol converter that converts the Euro-ISDN protocol into the Channel
Associated Signaling CAS protocol. Refer to the installation instructions, which are provided
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
>
In HiPath 3000/5000 V5.0 and later, the B channels in the TS2N (old: TS2) and
TS2R boards are subject to license. Consequently, the two boards below have
been assigned a new hardware identification code. The new codes prevent the
boards from being used in earlier versions. Functionality and layout of the
boards have not been changed.
