A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-1
Nur für den internen Gebrauch Boards for HiPath 3000
3 Boards for HiPath 3000
Chapter contents
This chapter covers the following topics:
Boards with additional primary protection
Topic
Section 3.1, “Functional and model overview of the boards”
Section 3.2, “Central Board”
Section 3.3, “Peripheral boards”
Section 3.4, “Options”
7
CAUTION
The system must be disconnected from the power source before removing or insert-
ing any boards in HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300, and be-
fore removing or inserting the central boards in HiPath 3800.
>
NOTE
Danger of damage to property due to surge voltage: Lines exiting buildings of the
boards listed below must be protected with an additional primary protection against
overvoltage caused by lightening strikes (see also Section 2.1.2, “Lightning Protec-
tion”).
● CBCC, CBRC, CBSAP ● STLSX2, STLSX4, STLSX4R ● TMDID, TMDID2
● SLA8N, SLA16N, and SLA24N ● STMD3, STMI2 ● TMEW2
● SLAD4, SLAD8, SLAD8R ● TCAS-2, TCASR-2 ● TMGL4, TMGL4R
● SLAD16 ● TLA2, TLA4, TLA8, TLA4R ● TMQ4, TST1
● SLC16N, SLCN ● TM2LP, TMAMF ● TS2N (old: TS2), TS2R
● SLMAE8, SLMAE ● TLANI2, TLANI4, TLANI8 ● 4SLA, 8SLA, 16SLA
● SLMA, SLMA8, SLMA2 ● TLANI4R ● 8SLAR
● SLMAV8, SLMAV24 ● TMANI, TMANI-IM, TMANI-BRA ● ALUM4, ANI4, ANI4R
● SLMO2, SLMO8, SLMO24 ● TMC16, TMCAS, TMCAS-2 ● GEE12, GEE16, GEE50
● SLU8, SLU8R ● TST1 ● REALS, STBG4
● STLS2, STLS4, STLS4R
