Siemens HiPath 3000 Series - Optipoint 500; Optipoint 500 Telephones; Optipoint 500 Entry

Workpoint Clients Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
10-82 HiPath 3000/5000 V9, Service documentation
wclient.fm
optiPoint 500
10.5.1 optiPoint 500 Telephones
10.5.1.1 optiPoint 500 entry
Main features
● 8 function keys with LEDs (can be modified with HiPath 3000/5000 Manager E; for infor-
mation on key programming, see Section 10.6)
● Open listening
● 2 volume adjustment keys (plus/minus) and pitch
● Suitable for wall mounting
● No modularity (no connection option for adapters or key modules), no display
Standard key assignment (default) for optiPoint 500 entry
Refer to Section 10.5.1.6 for connection requirements.
Figure 10-36 optiPoint 500 entry - Standard Key Assignment (Default)
Consultation hold
Redial
Message
Callback
Speed dialing
Microphone on/off
Loudspeaker
Disconnect
