Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
3.3.18 SLMAV8, SLMAV24
Introduction
For HiPath 3000/5000 V8 or later, the following boards can be used to connect analog stations
(analog telephones, Fax Group 3, etc.) in HiPath 3800:
● SLMAV8 (S30810-Q2227-X100) = 8 analog T/R interfaces
● SLMAV24 (S30810-Q2227-X200) = 24 analog T/R interfaces
The SLMAV8 and SLMAV24 boards are successor modules for the following boards:
● SLMA (S30810-Q2191-C300)
● SLMA2 (S30810-Q2246-X)
● SLMA8 (S30810-Q2191-C100)
● SLMAE [SLMAE200] (S30810-Q2225-X200)
● SLMAE8 (S30810-Q2225-X100)
Automatic migration to the boards SLMAV8 and SLMAV24 is not possible. The slot in HiPath
3800 must be released via HiPath 3000 Manager E
Main features
Code Receiver: A code receiver is available for each T/R interface (permits DTMF dialing at
analog telephones). This guarantees that all analog terminals connected are fully accessible.
CLIP: These boards support calling name identification presentation (CLIP).
External analog extensions:
● External analog extensions may only be connected via the SLMAV board.
● For U.S. only: The connection of external analog extensions via OPS signaling (OPS: Off-
Premises-Station) is not supported.
Ring voltage: The SLMAV board generates its own ring voltage of 71 V
eff
. An external ring volt-
age generator is therefore not required.
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
