Peripheral boards
3.3.13 SLC16N (not for U.S.)
Introduction
The SLC16N board is used in HiPath Cordless Office and connects base stations to
● HiPath 3550 (max. one SLC16N per system).
Chapter 11 contains basic information on the options available for the use of HiPath Cordless
Office.
Base stations must be clocked with a high degree of accuracy for HiPath Cordless Office. For
this, the subboard CMA or CMS must be plugged into the CBCC board (HiPath 3550) (see
Table 11-1).
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
>
For initial installation of HiPath Cordless Office, the HiPath cordless system number
(DECT ID) must be ordered together with the SLC16N board.
Replacement boards are always delivered without a HiPath cordless system num-
ber.
Installing the first SLC16N and entering the HiPath cordless system number releas-
es 16 mobile telephones for use (PIN numbers are assigned). These mobile units
can then be logged on to the system. Other mobile telephones must be released be-
fore they can be used (see Section 10.13.4).
>
The base stations BS3/1 (S30807-H5482-X), BS3/3 (S30807-H5485-X), and BS3/S
(X30807-X5482-X100) are being phased out and may no longer be ordered. You
must use the successor product BS4 (S30807-U5491-X) instead of the types
named.
You can still operate the base stations listed in HiPath 3000. Base stations BS3/1,
BS3/3, and BS4 can also be used in mixed mode.
