Nur für den internen Gebrauch Boards for HiPath 3000
Functional and model overview of the boards
3.1 Functional and model overview of the boards
Functional overview of all boards used
Table 3-1 HiPath 3000 - Functional Overview of All Boards Used
Board Part number Model
Central Board
CBCC S30810-Q2935-A401 HiPath 3550/HiPath 3350
CBRC S30810-Q2935-Z301 HiPath 3500/HiPath 3300
CBSAP S30810-Q2314-X HiPath 3800
CMA S30807-Q6931-X HiPath 3550/HiPath 3350/HiPath 3500/
HiPath 3300
CMS S30807-Q6928-X HiPath 3000
CUC S30777-Q750-X HiPath 3550
CUCR S30777-Q750-Z HiPath 3500
CUP S30777-Q751-X HiPath 3350
CUPR S30777-Q751-Z HiPath 3300
DBSAP S30807-Q6722-X HiPath 3800
IMODN S30807-Q6932-X100 HiPath 3000
LIM S30807-Q6930-X HiPath 3000
LIMS S30807-Q6721-X HiPath 3800
LUNA2 S30122-K7686-A1
S30122-K7686-M1
HiPath 3800
MMC S30122-X8002-X10 HiPath 3000
PSUP S30122-K5658-M HiPath 3350
RGMOD S30124-X5109-X HiPath 3800 (for selected countries only)
UPSC-D S30122-K5660-A300
S30122-K5660-M300
HiPath 3550/HiPath 3350
UPSC-DR S30122-K7373-A900
S30122-K7373-M900
HiPath 3500/HiPath 3300
