Functional and model overview of the boards
Peripheral boards
Note: The HiPath 3550, HiPath 3350, HiPath 3500 and HiPath 3300 peripheral boards must
be firmly inserted into their slots; otherwise contact problems can cause board failure.
16SLA S30810-Q2923-X HiPath 3550/HiPath 3350 (not for U.S.)
4SLA S30810-Q2923-X200 HiPath 3550/HiPath 3350 (not for U.S.)
8SLA S30810-Q2923-X100 HiPath 3550/HiPath 3350
8SLAR S30810-K2925-Z HiPath 3500/HiPath 3300
DIU2U S30810-Q2216-X HiPath 3800 (for U.S. only)
DIUN2 S30810-Q2196-X HiPath 3800
DIUT2 S30810-Q2226-X100 HiPath 3800
HXGR3 S30810-K2943-Z HiPath 3500/HiPath 3300
HXGS3 S30810-Q2943-X HiPath 3550/HiPath 3350
HXGS3 S30810-Q2943-X1 HiPath 3550/HiPath 3350
HXGS3 S30810-K2943-Z1 HiPath 3500/HiPath 3300
IVMN8 S30122-H7688-X100 HiPath 3800
IVMNL S30122-H7688-X HiPath 3800
IVMP8 S30122-Q7379-X100 HiPath 3350 (not for U.S.)
IVMP8R S30122-K7379-Z100 HiPath 3300 (not for U.S.)
IVMS8 S30122-Q7379-X HiPath 3550/HiPath 3350
IVMS8R S30122-K7379-Z HiPath 3500/HiPath 3300
SLA16N S30810-Q2929-X100 HiPath 3550
SLA24N S30810-Q2929-X HiPath 3550
SLAD4 S30810-H2956-X100 HiPath 3550/HiPath 3350
SLAD8 S30810-H2956-X200 HiPath 3550/HiPath 3350
SLAD8R S30810-K2956-X300 HiPath 3500/HiPath 3300
SLAD16 S30810-Q2957-X HiPath 3550/HiPath 3350
SLC16N S30810-Q2193-X100 HiPath 3550 (not for U.S.)
SLCN S30810-Q2193-X300 HiPath 3800 (not for U.S.)
SLMA S30810-Q2191-C300 HiPath 3800
SLMA2 S30810-Q2246-X HiPath 3800(for selected countries only)
SLMA8 S30810-Q2191-C100 HiPath 3800
Table 3-1 HiPath 3000 - Functional Overview of All Boards Used
Board Part number Model
