Installing HiPath 3800
4.1.5.8 Static Traffic Capacity
The static traffic capacity of the HiPath 3800 system can be determined as follows.
Table 4-5 HiPath 3800 - Static Traffic Capacity
HiPath 3800 Slots per PCM
segment
Static traffic capacity
per PCM segment
Total static traffic ca-
pacity of the system
Single-cabinet system
(see Page 4-46)
1 – 5 128 erlangs + (128 er-
langs
1
)
1 The basic cabinet provides two PCM highway bundles with 2 x 4 PCM highways each. DIUT2, DIUN2, DIU2U (for U.S.
only), and STMI2 use the PCM highways from trunk group F. Thus there are an additional 128 time-division multiplex chan-
nels available for these boards in the basic cabinet for slots 1 – 5 and slots 7 – 10. If HiPath 3800 is used as a two-cabinet
system, the PCM highway trunk group F cannot be used.
512 erlangs
7 – 10 128 erlangs + (128
erlangs
1
)
Two-cabinet system
(see Page 4-47)
1 – 5 128 erlangs
512 erlangs
7 – 10 128 erlangs
11 – 16 128 erlangs
18 – 24 128 erlangs
