Peripheral boards
3.3.36 TMC16 (for selected countries only)
Introduction
The trunk module TMC16 (Trunk Module Central Office) connects up to 16 analog ground-start
or loop-start trunks with the HiPath 3800.
Front panel
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
Figure 3-99 TMC16 (for selected countries only) (S30810-Q2485-X) - Front Panel
>
To ensure sufficient shielding, provide the board with a shielding panel. For informa-
tion on mounting the shielding panel, see Section 4.1.5.3.
Two LEDs indicating the board status:
● LED (red)
● LED (green)
