7 Starting HiPath 3000 as a Gateway

Introduction

So-called gateways provide the HiPath 5000 with interfaces for trunk and tie trunk connections

to the telecommunications network. For HiPath 3000 V9, HiPath 3800, HiPath 3500 and HiPath

3300 systems can be used as gateways.

Chapter contents

This chapter covers the following topics:

Topic

Starting HiPath 3800 as a Gateway, page 7-2

Starting HiPath 3500 as a Gateway, page 7-5

Starting HiPath 3300 as a Gateway, page 7-8
