Static Configuration Rules
2.4 Static Configuration Rules
2.4.1 Resources and Capacity Limits
With HiPath 3000/5000, HG 1500 provides the resources listed in Table 2-27 via the HG 1500
boards defined as media gateways (= gateway HG 1500).
Table 2-28 shows the board-specific capacity limits (maximum configuration) for the corre-
sponding functions.
>
For information on the configuration of HG 1500 boards, refer to the HG 1500 Ad-
ministration Manual.
Table 2-27 Technical Specifications (Resources) of the HG 1500 Boards Defined as Me-
dia Gateways
Resource HXGS3
HXGR3
STMI2
with-
out
PDM1
with 1
x
PDM1
Routing channels
A routing channel is required, for example, for making con-
nections between two IP networks via ISDN (ISDN routing).
16 16
Gateway channels (DSP channels)
A gateway channel is required, e.g., for the connection be-
tween an IP telephone/client and a TDM telephone.
816 32
Fax/modem channels (G.711) 8 16 32
Fax channels (T.38)
These are special hardware resources which facilitate fax
over IP functionality with the T.38 protocol.
23
Teleworker with AES encryption and codec G.711/G.729
(sampling rate 20 msec)
810
Teleworker with AES encryption and codec G.723 (sampling
rate 30 msec)
12 16
DMC channels
These are the gateway channels for Direct Media Connection
(DMC) with HiPath 4000 (DMC interworking feature is ac-
tive.
1
).
612 24
