Peripheral boards
3.3 Peripheral boards
Important information
Abbreviations for colors
The tables in this section use abbreviations to denote the colors of connector assignments. The
abbreviations used are as follows:
7
Caution
The system must be powered down and de-energized before removing or inserting
any boards in HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300, and before
removing or inserting the central boards in HiPath 3800.
>
The HiPath 3550, HiPath 3350, HiPath 3500 and HiPath 3300 peripheral boards
must be firmly inserted into their slots; otherwise contact problems can cause board
failure.
● wh: white ● rd: red ● bn: brown
● gr: gray ● gn: green ● bk: black
● ye: yellow ● bu: blue
● or: orange ● vi: violet
