Nur für den internen Gebrauch Boards for HiPath 3000
Central Board
3.2.3 CBSAP
Introduction
The CBSAP board (Central Board Synergy Access Platform) performs all central control and
switching functions for HiPath 3800 (see Figure 3-5).
Capacity
● DTMF transmitters: 12
● DTMF receivers: 12
● Tone generators: 16
● Dial tone receivers: 4
Subboards
The following subboards can be used depending on the application:
● CMS clock module (optional)
● MMC multimedia card
● IMODN integrated modem card new (optional)
● LIMS LAN interface module (optional)
Contains two Ethernet (10BaseT) LAN connectors (8-pin RJ45 jacks):
– LAN1 (administration via HiPath 3000/5000 Manager E and CTI functions)
– LAN2 (not assigned)
● Music on hold (optional):
– MPPI (Product of BEYERTONE GmbH)
– MUSIC (Product of Sound Player GmbH)
V.24 interfaces (9-pin SUB-D plug)
● Service (X50) = for connecting the service PC
● Application (X51) = for connecting a printer or application
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
