2.1.7 Peripheral components of the HiPath 3000 systems
2.1.7.1 Peripheral components, HiPath 3800
Subscriber Line Modules
Table 2-6 Subscriber Line Modules for HiPath 3800
Board
Name
Capacity Coun-
try
Type/Description
Ports per board B channels per board Boards per cabinet Max. number of boards per system ROW USA
IVMN8 8 8 1 1 x x These boards are for the integrated voicemail func-
tions of HiPath Xpressions Compact.
IVMNL 24 24 1 1 x x
SLCN 16 64 4 4 x SLCN board for connecting base stations to the sys-
tem.
SLMA 24 x x Board with 24 analog a/b interfaces
For Australia only: The T/R interfaces supply a ring
voltage of 35 V
eff
. Depending on the terminals con-
nected, we cannot exclude the possibility of errors oc-
curring during ringing state.
SLMA2 24 x
1
Board with 24 analog a/b interfaces
SLMA8 8 x x Board (8 analog interfaces)
For Australia only: The T/R interfaces supply a ring
voltage of 35 V
eff
. Depending on the terminals con-
nected, we cannot exclude the possibility of errors oc-
curring during ringing state.
SLMAE 24 x x Board with 24 analog a/b interfaces
SLMAE8 8 x x Board (8 analog interfaces)
SLMAV8 8 x x The SLMAV boards provide analog T/R interfaces and
replace the boards SLMAE, SLMA8, SLMAE200,
SLMA and SLMA8.
SLMAV24 24 x x
