Central Board
3.2.2 CBRC
Introduction
The CBRC board (Central Board Rack Com) performs all central control and attendant func-
tions for HiPath 3500 and HiPath 3300.
This description refers to the following versions of central CBRC board:
● CBRC S30810-Q2935-Z401: Implemented from V6.0 Rel. 10 or later and V5.0 Rel. 15 or
later.
Essential new functions:
– Integration of the functionality of the LIM subboard
– Increase of the ring voltage of analog station interfaces (T/R) to approx. 65 V
eff
● CBRC S30810-Q2935-Z301: implemented in V5.0 or later.
Essential new function: CLIP
Differences between both CBRC versions are indicated at the appropriate point in the following
description.
Subboards
The following subboards can be used depending on the application:
● Clock module CMA or CMS (optional)
● MMC multimedia card
● IMODN integrated modem card new (optional)
● Music on hold (optional):
– MPPI (Product of BEYERTONE GmbH)
– MUSIC (Product of Sound Player GmbH)
● Entry Voice Mail EVM (optional): Pluggable up to HiPath 3000/5000 V7, securely soldered
as of HiPath 3000/5000 V8.
● LAN Interface Module LIM (optional, for CBRC S30810-Q2935-Z301 only)
● External Music ModuleEXMR S30122-K7403-T (only for CBRC S30810-K2935-Z401)
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
