Starting HiPath 3800 as a Gateway
7.1 Starting HiPath 3800 as a Gateway
7.1.1 Prerequisites
Refer to Section 4.1.1 for information on the tools and resources needed to install the HiPath
3800 system.
7.1.2 Procedure for Installation and Startup
7
Warning
Only authorized service personnel should install and start up the system.
>
To ensure that IP addresses are not assigned more than once in the customer net-
work, you must ping each new IP address to be configured before each IP address
is assigned. If an IP address responds, then this address cannot be used again.
7
Caution (for Brazil only)
The use of the outlet strip with overvoltage protection with part number C39334-
Z7052-C33 is absolutely mandatory. The AC power of the system cabinet(s) must
be conducted through the outlet strip with overvoltage protection.
Table 7-1 HiPath 3800 as a GW, Procedure for System Installation and Startup
Step Activity (Remarks)
Installing HiPath 3800 (19-Inch Cabinet)
1. Selecting the Installation Site, page 4-20(generally determined by the existing 19-
inch cabinet)
2. Unpacking the Components, page 4-23
3. Mounting System Cabinets in the 19-Inch Cabinet, page 4-24
4. Grounding the System, page 4-27
Checking the Grounding, page 4-30
5. Connecting the Cable to the Backplane, page 4-51
6. If required: Inserting the External Patch Panel, Page 4-66
7. Loading the System Software and Installing Subboards on the CBSAP, page 4-81
8. Installing Boards (Configuration Notes), page 4-31 (cabinet(s) are already
equipped with the boards)
We recommend that you check the board population using the configuration notes.
