Installing HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
4-2 HiPath 3000/5000 V9, Service documentation
inst_h3.fm
Installing HiPath 3800
4.1 Installing HiPath 3800
4.1.1 Installation Prerequisites
Tools and resources needed
The following are needed for installing the HiPath 3800 system:
● Tools:
– Hex or open-end wrench, 8 mm, open-end wrench 13 mm
– Diagonal cutting pliers, telephone pliers, wire stripper, flat-nosed pliers
– Slotted screwdrivers, from 2 to 8 mm (1/4 to 5/16 in.)
– Phillips or cross-point screwdrivers, sizes 1 and 2
– TORX screwdriver
– Wire stripper (for example, from Krone)
– Board wrench (part no. C39300-A7194-B10)
– Electric drill, hammer
– Level, tape measure
– For U.S. only: Punch-down tool suitable for the block used (such as block 66)
● Resources:
– Assistant T or HiPath 3000/5000 Manager E
– Digital multimeter for testing ground connections and partial voltages
– Telephone test set for analog interfaces
– Not for U.S.: ISDN tester (such as K3000 or Aurora)
– For U.S. only: Aurora
Duet
, Aurora
Expert,
Aurora
Remote
or similar, ISDN protocol analyz-
er
7
Warning
Only authorized service personnel should install and start up the system.
