Peripheral boards
3.3.37 TMCAS (for selected countries only)
Introduction
For V1.0 and later, TMCAS (Trunk Module Channel Associated Signaling) boards can be used
in HiPath 3550 to support the country-specific CAS protocol.
The board converts the Euro-ISDN protocol on an S
2M
link into the Channel Associated Sig-
naling (CAS) protocol. The board functions only in connection with a TS2N (HiPath 3550).
There is no direct connection between the TMCAS board and the system’s central control unit.
The TMS2/TS2N handles all signaling and data traffic.
>
NOTE
Danger of damage to property due to surge voltage. The required lightning protec-
tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-
tion”.
